Description
FR7000 Series
High-Performance Fixed UHF RFID Reader
A superior integrated UHF RFID reader powered by the Impinj E710 chip, delivering unmatched reading speed and accuracy for demanding enterprise and industrial environments.
Key Features
Superior UHF RFID Performance
Equipped with the **Impinj E710 chip**, the reader achieves a remarkable reading speed of up to **1300+ tags per second** and an impressive **99.7% accuracy** rate, even for swiftly moving items.
Dual Antenna Versatility
Available with either a **6dBi** (range over 7m) or a **9dBi** (range over 12m) circularly polarized antenna, meeting diverse reading distance demands across various applications.
Industrial-Grade Durability
Built with a robust plastic and aluminum alloy casing, featuring **IP67** industrial-grade dust and waterproof protection, ensuring resilience against harsh environmental factors like oil and moisture.
Rich Interface Connectivity
Supports standard **RS232 and RJ45** interfaces, with optional support for **RS485, Wiegand, GPIO, and USB 2.0**, allowing flexible integration into existing systems.
Technical Specifications
| Protocol | ISO18000-6C (EPC C1G2) |
|---|---|
| Frequency | 860~960MHz (Adjustable) |
| Chip | Impinj E710 |
| Output Power | 0-33dBm (Adjustable) |
| Antenna Options | 6dBi / 9dBi Circularly Polarized Antenna |
| Typical Reading Range | Over 7m (6dBi) / Over 12m (9dBi) |
| Power Supply | +9V DC, PoE (Optional) |
| Interfaces (Standard) | RS232, RJ45 |
| Protection | IP67 |
| Dimensions (9dBi) | 257mm × 257mm × 52mm (Weight: 1800g) |
| Dimensions (6dBi) | 130mm × 130mm × 50mm (Weight: 600g) |
